Mfiridwuma ho nsɛm .

Nhwɛsoɔ	Tumi	Kɛseɛ	Rated mprempren .	Input ahoɔden a ɛwɔ mu .	OUTPUT . Voltage .	Ɔfa	Nsɛm a wɔde hyɛ mu mpɛn pii .	Output frequency .	Mobile Phone App Control Dwumadi . (wɔayɛ no sɛnea wɔpɛ) .	Nhyɛso sensor .
VFA-10M .	0.75kW .	186 * 154 * 116mm .	4.8A	1×220V	1×220V	Single-fase wɔ mu na ɛyɛ biako-fase fi .	50/60Hz .	20-50/60Hz .	Nneɛma a wɔde tua ho ka foforo .	4-20MA . +24V 10Bar .
	1.1kW .	210 * 173 * 124mm .	7A
	1.5kW .	210 * 173 * 124mm .	9.6A
	2.2kW .	210 * 173 * 124mm .	11.5A
	3KW .	250 * 240 * 170mm .	13A
VFA-10S .	0.75kW .	186 * 154 * 116mm .	3.4A	1×220V	3×220V(△)	Single-fase wɔ mu na ɛwɔ afã abiɛsa fi mu .
	1.1kW .	186 * 154 * 116mm .	5A
	1.5kW .	210 * 173 * 124mm .	6.8A
	2.2kW .	210 * 173 * 124mm .	9.6A
VFA-10t .	1.1kW .	210 * 173 * 124mm .	3.2A	3×380V	3×380V(Y)	Nneɛma abiɛsa a wɔde hyɛ mu, nea ɛwɔ afã abiɛsa .
	1.5kW .	210 * 173 * 124mm .	4.3A
	2.2kW .	210 * 173 * 124mm .	5A
	4KW .	250 * 240 * 170mm .	9.3A							4-20MA . +24V 16Bar .
	7.5kW .	250 * 240 * 170mm .	17.4A							4-20MA . +24V 16Bar .

product-850-850

Mfiridwuma ho nsɛnkyerɛnne .

Dabi{0}}	Product Specification .	0.75kW .	1.1kW .	1.5kW .	2.2kW .	3KW .	4.0KW .	7.5kW .
1	Input tumi .	AC tumi a ɛwɔ afã biako anaasɛ AC ahoɔden a ɛwɔ afã abiɛsa .					AC ahoɔden a ɛwɔ afã abiɛsa .
2	Input ahoɔden a ɛwɔ mu .	110VAC anaa 220VAC anaa 380VAC .					380Vac .
3	Wɔma kwan ma voltage nsakrae .	80V~140V(110V) anaa 160V ~ 260V(220V) anaa 320V ~ 450V(380V)
4	Nsɛm a wɔde hyɛ mu mpɛn pii .	50/60Hz .
5	Output voltage .	110VAC anaa 220VAC anaa 380VAC .
6	Load Type .	pɔmpɛ .
7	Output frequency range .	20-50/60Hz .
8	Nhyɛso sensor .	24V, 4-20MA (10bar, 16bar, 25bar) .
9	Nhyɛso nhyehyɛe a ɛwɔ hɔ .	0.5 ~ 9.0bar .
10	Nhyɛso tank nhyehyɛe ahwehwɛde .	Wɔhwehwɛ sɛ ɛnyɛ nea ennu lita 2 inflatable pressure nsu tank(preset pressure{1}}% wɔ nhyehyɛe nhyɛso) .
11	Ɔhyew a ɛkɔ soro .	0~+40 abodin krataa .
12	Kwan	Nsu a ɛho tew wɔ ɔhyew a ɛwɔ 0~+100℃mu .
13	Nhyɛso a wɔhwehwɛ bere a obi fi ase yɛ ne ho no .	Bere a adwumayɛbea nhyehyɛe no nhyɛso no nnu 0.3 bar .
14	Installation .	Hwɛ sɛ asase no fata na wotumi de ho to so ansa na wode.

Abisadeɛ

Tap nsu a ɛma ahoɔden nhyehyɛe .
Nsuo a wɔde ma wɔ fie ne nea wɔte mu ho nhyehyɛe .
Swimming pool nsu a wɔde ma ho nhyehyɛe .
Nsu a wɔde ma wɔ aguadi mu ho nhyehyɛe .
Factory dormitory nsu a wɔde ma ho nhyehyɛe .
Mfiridwuma mu nsu a ɛkɔ nipadua no mu .
Nsu a ɛma onwini .
Nsu a ɛyɛ nwini a ɛkɔ nipadua no mu .

Nneɛma a wɔyɛ .

Saa variable frequency drive inverter yi yɛ nea wɔde di dwuma titiriw ma nsu pɔmpɛ, ɛfa industry anim kwan SPWM ne pressure transmission technique, hu ankasa pipeline nhyɛso nsakrae na ɛhwɛ rotation ahoɔhare a pump.

Installation no yɛ mmerɛw yiye ne direct screw thread, wobetumi de adi dwuma ahorow ahorow nsu pɔmpɛ na ɛnam so atew extra costs.
Saa VFD inverter yi yɛ adwuma yiye, ebetumi akora nsu ne anyinam ahoɔden so akodu 20% ~ 60% sɛ wɔde toto atetesɛm mu nsu a wɔde ma nhyehyɛe ho.

Range voltage no yɛ wuram, ebetumi ayɛ adwuma styab wɔ mmeae a voltage nsakrae kɛse.

Soft starting and stoppping, nsuo nhyɛsoɔ a ɛkɔ so daa no ma paipu ntam nkitahodiɛ nkwa nna yɛ tenten na ɛma nsuo a wɔde di dwuma no yɛ ahotɔ na ɛyɛ anigyeɛ.

Saa afiri yi dwumadie no yɛ mmerɛw paa, wobetumi awie dwumadie nyinaa denam parameters setting so, ɛho nhia sɛ wɔyɛ adwumayɛfoɔ a wɔyɛ adwumaden biara debug.

LED display ma ɛyɛ mmerɛw na ɛyɛ ntɛm sɛ wobɛhwɛ na wode nhyɛso ankasa botae ahorow asi hɔ.

FAQ .

Asɛmmisa: So woyɛ adwumakuw a woyɛ adwuma anaasɛ wudi gua?
A: Yɛyɛ manufacturer wɔ Ningbo, China. adwumayɛbea titiriw yɛ inverter, daa magnet inverter pɔmpɛ, inverter swimming pool pump, photovoltaic inverter deep well pump, inverter circulating pump, inverter nsu ase pump ne nsu pɔmpɛ controller. adwumayɛbea no atwam iso9001 Quality System, ne pii product

Asɛmmisa: So wubetumi akyerɛ me sɛnea mede pɔmpɛ inverter a ɛka float switch no ho bedi dwuma?
A: Sɛ wɔde inverter no bata float switch no ho wie a, wobetumi de inverter menu no asi hɔ. wɔ nhyehyɛe akyi, sɛ ɛyɛ drainage system a, nsuo a ɛkɔ soro no yɛ adwuma na nsuo a ɛba fam no gyina. wɔ nsuo a wɔde ma nhyehyɛeɛ no mu no, ɛyɛ adwuma wɔ nsuo a ɛba fam no mu na ɛgyina nsuo a ɛkɔ soro.

Q: So MOQ wɔ wo product no mu?
A: Yɛyɛ adwumayɛbea a wɔyɛ nneɛma, sɛ OEM anaa ODM nyɛ nea wɔhwehwɛ a, mpɛn pii no yenni dodow a ɛba fam koraa a wɔhwehwɛ. sɛ OEM nnwuma ho hia a, dodow a ɛba fam koraa a wɔkra no yɛ pcs 300 ma mfonini biara wɔ nhyehyɛe biako mu. sɛ customization of colors hia a, MOQ yɛ 1000 pcs ma biara model wɔ biako mu wɔ nhyehyɛe biako mu.

Asɛmmisa: Wo quality control system bɛn?
A: Yɛwɔ strict quality control system fi raw material procurement, production to product testing, biribiara a wɔyɛ no yɛ ɔbrɛ sɔhwɛ, calibration, temperature compensation ansa na wɔde amena. quality a ɛkorɔn no yɛ nea wɔahyɛ ho bɔ.

Asɛmmisa: Dɛn ne wo nneɛma ho adansedi krataa? Na akyi-tɔn adwuma?
A: Yɛn warranty bere yɛ asram 12 wɔ shipment akyi, na yɛn after-sales department no bebua wo nsɛmmisa wɔ 24hrs, akyirikyiri nkyerɛkyerɛ denam PC network so wɔ hɔ bere nyinaa na yɛde nkwa nna mu nsiesie.

Asɛmmisa: So wubetumi de nneɛma a wɔde kyekyere nneɛma ho ho nsɛm ama?

A: Wɔ inverter ahoɔden a ɛwɔ ase 2.2kW no, 6pcs wɔ CTN mu; Sɛ ɛyɛ 4kW ne 7.5kW inverters a, 4pcs wɔ CTN mu .

Asɛmmisa: Dɛn ne bere a wode yɛ wo nneɛma no?
A: Yɛyɛ factory, yɛn lead time no bɛyɛ20-45 adwuma nna.

Asɛmmisa: Inverter dodow ahe na wobetumi de abɔ mu wɔ intanɛt so sɛ ɛboro so a?

A: Yɛn inverters no betumi abɔ 6 devices no mu bere koro mu .

Asɛmmisa: Dɛn ne wo inverter no nhyɛso ho nhyehyɛe? Nneɛma bɛn na ɛtaa de nhyɛso a ɛma obi tumi yɛ ade no yɛ adwuma?

A:Frequency converters ne variable frequency water pumps a yɛyɛ no wɔ starting pressure a ɛyɛ 0.3bar ne pressure regulation range a ɛyɛ0.5-9BAR. mpɛn pii no, 5L pressure tank no yɛ nea wɔde di dwuma bere a wɔde di dwuma. nokwarem no, 8L anaa 12L pressure tank nso betumi ayɛ nhyehyɛe.

Asɛmmisa: So wowɔ sensor a ɛwɔ mu ne five-way inverters?

A: Yiw, yɛyɛ inverters a ɛwɔ sensor ahorow a ɛwɔ mu ne anum-way? Dɛn ne tumi ne dodow a wuhia?

Asɛmmisa: So wobetumi de frequency inverter a woyɛ no adi dwuma ama deep well pumps? Dɛn ne ahwehwɛde ahorow no?

A: Wobetumi de frequency inverters a yɛyɛ no adi dwuma ama deep well pumps, na tumi nhama no tenten ntumi ntra mita 20. Ɛsɛ sɛ frequency inverter no tumi yɛ kɛse sen deep well pump.

Q: So input frequency a ɛwɔ inverter mu no betumi ayɛ 50Hz na output frequency no ayɛ 60Hz?

A: Input frequency ne output frequency no yɛ pɛ, sɛ input frequency no yɛ 50Hz a, output frequency no yɛ 50Hz.

Asɛmmisa: Dɛn ne PV inverter deep well pumps a wɔtɔn no yiye no?

A: PV inverter a wɔtɔn no yiye no mu dɔ a emu dɔ pɔmpɛ titiriw yɛ 2 inch, 3 inch ne 4 inch PV inverter deep well pumps.

Asɛmmisa: So wubetumi ayɛ frequency converter ne daa magnet frequency conversion pump a OEM anaa ODM yɛ?

A: Yiw, yɛwɔ adwumayɛfo mfiridwuma kuw ne adeyɛ kuw wɔ yɛn adwumayɛbea. nneɛma a wɔyɛ wɔ yɛn adwumayɛbea nyinaa betumi ayɛ OEM anaa ODM, nkutoo na ɛwɔ hɔ a ɛne no hyia MOQ ahwehwɛde, aseda!

Tags a ɛyɛ hyew .: Pump inverter a ɛwɔ float switch, china, wɔn a wɔde nneɛma ma, adwumayɛbea, nea wɔayɛ no sɛnea wɔpɛ, ne bo yɛ mmerɛw, bo a wɔbɔ, nsɛm a wɔka kyerɛ

Pɔmpɛ inverter a ɛwɔ float switch .
